High Precision SMT Online AOI, PCB Automated Optical Inspection Machine

FOB Reference Price:Get Latest Price
$30,000.00 - $54,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
ETA
Model Number:
ETA
Name:
SMT Online AOI Machine
Application:
SMT PCB Assembly Line
Usage:
SMT, PCB, SMD, LED
PCB Size:
50*50mm ~ 400*400mm
Warranty:
1 Year
Product name:
ETA SMT PCB Online AOI Machine
Dimension:
1000*1020*1400mm
Weight:
600KG
Applicable Components:
0402, 0603, 0805, 1206, QPF, SOP, BGA
Type:
SMT Machine Related Products
Supply Ability
Supply Ability:
50 Set/Sets per Month
Packaging & Delivery
Packaging Details
Vacuum packed in wooden cases
Port
Hongkong
Product Description

High Precision SMT Online AOI, PCB Automated Optical Inspection Machine

Features:

1. 5 million pixels full color CCD camera, meet the test needs of 01005 components, and also achieve higher inspecting speed.

2. Stroboscopic ring pagoda RGBW four color ring light source.

3. With analysis of error distribution, DPPM change and confirmation of NG point functions.

4. Automatic generates the statistical analysis and data reports, enable the factory manager to get the process information at real time and guarantee their products' quality.

5. Have a more accurate and comprehensive feature extraction method, achieved a higher detection rate and lower false alarm.

Specifications
SMT On-line AOI Machine(Automated Optical Inspection)
Programming mode
Automatic writing, manual writing, CAD data import, automatic mapping component library
Detection mode
Cover the entire circuit board to optimize detection. Panel form and multi-mark with bad mark function
Test type
Solder paste printing coverage, offset printing, open solder, short solder, presence/ absence component, offset placement, skew, tombstone, wrong component, black pad contamination, solder pad chipout.
Image recognition
Depending on the detection point automatically set its parameters (such as offset, polarity, short circuit, etc.)
X, Y accuracy
<10um
PCB size
50*50mm (Min) ~ 400*400mm (Max), can be customized larger
Minimum parts test
0201 chip & 0.3pitch IC
Image processing speed
01005 chip<9ms
Weight
600KG
Dimension
1000*1020*1400mm
Air pressure
0.5MPa
