Automatic SMT AOI Inspection System for SMT LED Line ETA-415 from China

FOB Reference Price:Get Latest Price
$20,000.00 - $36,000.00 / Sets | 1 Set/Sets (Min. Order)
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 Negotiable
Contact Supplier
Loading...
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
ETA
Model Number:
ETA-415
Name:
SMT Off-line AOI Machine
Model:
ETA-415
Usage:
SMT, PCBA, PCB
PCB Size(mm):
50*50 ~ 430*330
Mini Component:
15um: 0201 chip & 0.4 pitch IC
Warranty:
1 Year
Dimension:
890*960*1310mm
Power Supply:
AC 220, 50/60Hz, <0.5Kw
Operation System:
Windows 7
Weight:
480Kg
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
Vacuum packed in wooden cases
Port
Shenzhen
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 To be negotiated
Video Description
Product Description

Automatic SMT AOI Inspection System for SMT LED Line ETA-415 from China

Features:

◆ Fast programming design, multi program running, multi application design, high precision, high NG output.

◆ Automatic barcode reading, intellectualized coaxial light design, multi mark(Bad Mark included).
◆ Seamless connection between SPC and AOI, take measures to avoid problem according to the feedback,control the quality in time.

◆ Using coaxial four-level illumination to make the part in the best status of brightness and softness.
◆ High precision intellectualized camera read the barcode automatically, with high speed and clearer images.

◆ Good stability(GR&R<10% @6 Sigma, CPK>1.33), test deviation accuracy less than ±0.25mm.
◆ Read 2D Barcode(laser&print).

Specifications
SMT Off-line AOI ETA-415
Test Board
After reflow soldering
Program Mode
Offline programming, check and control remotely through network
Resolution/Range/Speed
15um/Pixel FOV: 38*31mm, Test speed<0.25sec/FOV
Inspection Item
Component test, soldering test
Special Function
Read barcode, two sides of program test, multi board and multi program test
Mini Component
15um: 0201chip & 0.4pitch IC
PCB Size
50*50 ~ 430*330 mm
X/Y Driver
AC servo driver, repeat accuracy 0.01mm
Power Supply
AC 220 50/60Hz,<0.5Kw
Light
RGB ring tower LED light(Color light)
Dimension/Weight
890 * 960 * 1310 mm / 480 kg
Related Products

SMT Stencil Printer

SMT Pick and Place Machine

SMT Reflow Oven

SMT Production Line

PCBA Cleaning Machine


PCB Coating Machine


Company information

Why Choose Us:

ETA is the leading SMT factory solution provider in China, offering professional SMT factory building advice and service.
We have 24 years experience about SMT factories, offering full solution for global clients with our advantaged sources in China. Our core technology team members are all from Foxconn, Huawei, Siemens and other companies. We not only provide a full set of equipment, we also provide full SMT technical support and services.

Main Products: SMT LED Pick and Place Machine, SMT LED Reflow Oven, SMT LED Stencil Printer, SMT Production Line, LED Assembly Line, SMT LED Machine, etc.

Successful Experience:
ETA's customers in 35 countries around the world.
※ We have been helping customers to build a lot of new factories around the world.
※ Training more than 500 experts and technicians for customers.
※ Became the most reliable Chinese partner for you.


Our Factory


Our Team

Our Customers

ETA Engineers installed in Vietnam

ETA Engineers installed in Russia

ETA Engineers installed in Iran


Customers Visited Our Factory

Exhibition


Certifications

Packing & Delivery

Packing Method:

※ Standard wooden package

Shipping Ways:
※ By air, for sample and small package,international express
like DHL, UPS, EMS...
※ By sea, for large package and quantity;
※ Other ways as customer requested.

Delivery Time:
※ 35 Days
Our Service

■ Pre-Consultation: provides professional SMT solutions for the full line.


■ Factory Warranty: One-year warranty factory service.

■ Installation: On-site installation and commissioning, to ensure smooth production.

■ Technical Training: provides professional training from Level 1 to Level 3.

■ Technical Support: provides 7 * 24 technical support.

■ Software Upgrade: offers lifetime free software upgrades for all products.
FAQ

1. Are you a trade company or a manufacturer?
→ OEM & ODM service are available.

2. What is your delivery date?
→ The delivery date is about 35 days after receipt of payment.

3. What are your payment terms?
→ 30% deposit in advance and 70% balance before shipment.

4. Your main customers?
→ Huawei, Foxconn, Vtech, Sumida, Kemet, Vishay, Bosch, Canon.
